RADWIN2000UserManual Release2.8.30 18‐2

UpgradinganInstalledLink

Figure18‐1:SoftwareUpgradeUtility‐Mainwindow

ThedefaultsitesshownintheSoftwareUpgradelistpanelbelongtothecurrently

link.ThelistmaybeemptyifyouarerunningtheRADWINManager“offline”.

2.ClickAddSitetoaddadditionalsitesforupgrade.

Figure18‐2:Addsiteoptions

ClickAddSingleSiteforonesiteonly:

Warning

Whatfollowsaboutaddingsitesmanuallyorfromalistfile,assumesthatall

sitestobeupgradedareofthesametype‐eitherWinLink1000orRADWIN

2000.butnotboth.Thiswillnotworkwithamixedlist.
