RADWIN2000UserManual Release2.8.30 9‐7

IPAddress,VLANandProtocol

ForfurtherdetailsaboutHSS,seeChapter11.

IPAddress,VLANandProtocol

ConfiguringtheODUAddress

Eachsitemustbeconfiguredseparately.Foranover‐theairconfiguration,firstconfiguresite

BthensiteAsoastoavoidlockout.SeeChapte r26fordetailedinstructionsaboutthebest

waytodothison‐site.

SeeChapter17forfurtherdetailsaboutVLANFunctionalityforRADWIN2000.

 TodefinetheManagementAddresses:

1.Chooseasitetoconfigure.TheConfigurationdialogboxopens:
