RADWIN2000UserManual Release2.8.30 5‐11
Firststeps
Firststeps
AtthispointthemainwindowoftheRADWINManagershouldbedisplayed:
Figure5‐10:OpeningRADWINManagerwindowpriortoinstallation‐UsingIDU‐Cs
AdetailedfieldbyfielddescriptionofthecontentsoftheRADWINManagermainwindow
maybefoundinChapter7.
Theprocedurerequiredtomakethelinkfunctionalhasthreephases:
1. LinkInstallation‐whichwewilldetailbelow.
Installationactuallygetsthe linkoperationalbysettingthelinkparameters.Itusesafixed
channelatthelowestpossiblemodulation,BPSKat6.5Mbpsandwillworkunderthe
harshinterferencecondition.
2. LinkConfiguration‐describedinChapter8.
Note
TheDynamicTxRatiobaronlyappearsformodelRADWIN2000C
Note
Duringtheinstallationprocedure,thedefinitionoflink‐wideparametersis
automaticallyappliedtobothsidesofthelink.
