RADWIN2000UserManual Release2.8.30 6‐12
Installation
Figure6‐12:Ant ennatypechangewarning
3.Repeattheprocessforthesecondsite.
4.AtthesametimeyoucansettheAntennaGainandCableLoss.
TheTxPower(perradio)indicatesthepowerofeachradioinsidetheODUandis
usedforLinkBudgetCalculations.TheTxPower(System)showsthetotaltransmis‐
sionpoweroftheODUandisusedtocalculatetheEIRPaccordingtoregulations.
IfyouchoosetosettheAntennaGainandCableLoss,youwillreceivethefollowing
warningmessage:
Note
ForRADWIN2000BLinks:
TheseODUsmaybeswitchedbetweentheSFFembeddedantennaand
externalantennas.Tothisend,theAntennaConnectionTyperadiobuttons
arealwaysenabled:
UsetheIntegratedradiobuttontoenabletheembeddedantenna.
ObservethattheSFFembeddedantenna functionsasadualantennaand
cannotbechanged.
Note
ToseetherelationshipbetweenTxPower(radio)andTxPower(system),
notethat sothatifyoudoublethepower
inmilliWatts(fortworadios)thendBmwillincreaseby .
dBm 10 milliWatt
10
log=
10 2 3
10
log
