Radwin 2000 - Chapter 4: Hardware Installation

RADWIN2000UserManual Release2.8.30 4‐1
Chapter4:
HardwareInstallation
Thischaptersetsouttherequirementsandproceduresforthehardwareinstallationand
alignmentofaRADWIN2000linkinaccordancewiththepriorplanningassetoutinChapter
3.Itisintendedtoguidequalifiedfieldtechnicians.
Thischaptercoversthefollowingtopics:
• Unpackingandcheckingsuppliedequipment:
• ODUs
• IDUs
• PoEdevices
• IDU‐Haggregationunit
• Antennas
• Accessories
• Toolsrequiredforinstallation
• Safetypractices
• MountinganODU
• ConnectinganODU
• GroundingandlightningprotectionforanODU
• Networkconnection
• Poweringup
Note
ThematerialinthischapterisgenerictoallRADWINradiolinkproducts
unlessstatedotherwise.
Warning
OutdoorunitsandantennasshouldbeinstalledONLYbyexperienced
installationprofessionalswhoarefamiliarwithlocalbuildingandsafety
codesand,whereverapplicable,arelicensedbytheappropriate
governmentregulatoryauthorities.Failuretodosomayexposetheend
userortheserviceprovidertolegalandfinancialliabilities.RADWINandits
re‐sellersordistributorsarenotliableforinjury,damageorviolationof
regulationsassociatedwiththeinstallationofoutdoorunitsorantennas.
