RADWIN2000UserManual Release2.8.30 16‐2

RADWINEthernetRing

•RingProtectionMessage(RPM)‐controlmessageusedtomonitorandcontrolthering.

RADWINEthernetRing

ThefollowingfiguredescribestheRPLbehaviorduringaringfailureandrecoverycycle.

Figure16‐1:RingProtectionmechanism

Note

RPMmessagesarebroadcast,soitisessential(topreventflooding)to

associatetheRPLandmemberRingLInkswithaVLANID.Thisrequiresin

turn,thatequipmentusedintheringeithersupportsVLANorcan

transparentlypassthroughVLANtaggedpack ets.
