TheIDU‐H:AnAlternativetoPoEDevices

Figure4‐33:IDU‐Hpowerconnectors,groundinglugandpowerplug.
• Fordire ctDCconnection:Theconnectorsare3pininlinefemale,withpolarities(leftto
right)minus,ground,plus.
• ForACconnection:ToavoiddamagetotheIDU‐H,alwaysuseanAC/DCadapterand
powerplugsuppliedbyRADWIN.
IDU‐H‐FunctionalOverview
Figure4‐34:IDU‐Hfrontpanel
Thefrontpanelisverystraightforward:TheSFPportsarestandard.TheLANportsare
EthernetandsupportGbE.ThesixODUWANportsfunctionidenticallytotheLAN‐Outport
onaPoEdevice.
Warning
Groundtheunitwitha10AWGwirebeforeapplyingpower.
