RADWIN2000UserManual Release2.8.30 D‐2
InterfaceAPI
InterfaceAPI
ControlMethod
TheRADWINManagerapplicationprovidesallthemeanstoconfigureandmonitora
RADWIN2000link,communicatingwiththeSNMPagentineachODU.EachSNMPagent
containsdataoneachoftheIDUsandODUsinthelink.Bothagentscommunicatewitheach
otherovertheairusingaproprietaryprotocol.
TocontrolandconfigurethedeviceusingtheMIB,youshouldadheretothefollowingrules:
• Theconnectionforcontrolandconfigurationistothelocalsite,overanySNMP/UDP/IP
network.
• AllParametersshouldbeconsistentbetweenbothoftheODUs.Notethatinconsistency
ofairparameterscanbreaktheairconnection.Tocorrectairparametersinconsistency
youmustreconfigureeachoftheODUs.
• Commonpracticeistoconfiguretheremotesitefirstandthentoconfigurethelocal
site.
• Forsomeoftheconfigurationparametersadditionalactionmustbetakenbeforethe
newvalueisloaded.Please refertotheoperationintheparametersdescription.
• SomeoftheMIBparametersvaluesareproductdependent.Itisstronglyrecommend
usingtheRADWINManagerApplicationforchangingthesevalues.Settingwrongvalues
maycauseindeterminateresults.
CommunityString
Tocontrolalink,allSNMPrequestsshouldgotothelocalsiteIPaddress.
SeeTable5 ‐2fordefaultCommunitystrings.
PrivateMIBStructure
ThesectionsintheprivateRADWINMIBanditslocationintheMIBtreeareshownin
FigureD‐1below:
Note
EachODUhasasingleMACaddressandasingleIPaddress.
