RADWIN2000UserManual Release2.8.30 9‐28
VLANTaggingforEthernetService:Configuration
VLANTaggingforEthernetService:Configuration
TwomodesofVLANtaggingforEthernetservicearesupported:ODUmodeforPoElinksand
IDUmodeforlinksusingIDU‐Cs.
VLANTagging‐ODUMode
IftheODUisconfiguredwitheither
• aPoEdeviceinsteadofanIDU‐C
• anIDU‐CwithIDUdetectiondisabled
thewindowshowninFigure9‐15willbedisplayed.ClickingtheODUVLANConfiguration
buttonopensthefollowingwindow:
Figure9‐17:ODUVLANConfiguration
TheIngressoptionsare:
Tip
VLANIDsareusedbyRADWINproductsinthreeseparatecontexts:
ManagementVLAN,TrafficVLANandEthernetRing.Itisrecommended
thatyouusedifferentVLANIDsforeachcontext.
