RADWIN2000UserManual Release2.8.30 9‐35
SettingtheMaximumInformationRate(MIR)
again.Youhave“twominutesofgrace”before theVLANsettingstakehold.Duringthis
period,youshouldnavigatetoSiteConfiguration|EthernetandthenclicktheDisableVLAN
button.AnyVLANsettingsforthesitewillbelost.
SettingtheMaximumInformationRate(MIR)
WhatistheMIR
ThemaximumEthernetthroughputofthelink (MIR)canbelimited.ThedefaultsettingisBest
Effort(seeFigure9‐14above),wherethehighestinformationrateavailableforthelink
conditionsandsettingsisused.
Whatisitfor
TheMIRsetting limitsthethroughputforEthernetservice.Itdoesnotaffectthecapacityof
TDMservices.
IftheLinkBudgetCalculatororairconditionslimitthecapacitytoXMbps,andsupposethat
youuseY(<X)MbpsforTDMservices,thenyouareleftwithX‐Y=ZMbpsforEthernet.
Supposeforexample,thatZ=20Mbps.
AsaServiceProvider,youcandecidetosellapackagebasedon10Mbpsandcharge$P1for
it,or15Mbpsfor$P2>$P1.
TheMIRsetting allowsyoudothis.
Thedefaultvalueis“besteffort”(shownas“Unlimited”)whichwillgiveZabove.
 TolimittheEthernetinformationrate:
1.FromtheConfigurationmenu,choosethesitetoreconfigure.
2.ClickAdvanced|Ethernet
TheConfigurationdialogboxopens.
Note
Theminimumvalueis 256Mbps.
ThemaximumvaluewillbetheminimumbetweenZaboveand‐
• 25/10MbpsforRADWIN2000A(Modeldependent)
• 50MbpsforRADWIN2000B
• 20MbpsforRADWIN2000X
• 200MbpsforRADWIN2000C
TheMIRsettingisindependentperdirection.
