REXROTH EFC 3610 Series User Manual

Code Name Setting range Default Min. Attri.
E3.60 Stage 0 action
011, 012, 013, 014, 015, 016 ,017,
018, 021, 022, 023, 024, 025, 026,
027, 028, 031, 032, 033, 034, 035,
036, 037, 038, 041, 042, 043, 044,
045, 046, 047, 048, 051, 052, 053,
054, 055, 056, 057, 058, 061, 062,
063, 064, 065, 066, 067, 068, 071,
072, 073, 074, 075, 076, 077, 078,
081, 082, 083, 084, 085, 086, 087,
088, 111, 112, 113, 114, 115, 116,
117, 118, 121, 122, 123, 124, 125,
126, 127, 128, 131, 132, 133, 134,
135, 136, 137, 138, 141, 142, 143,
144, 145, 146, 147, 148, 151, 152,
153, 154, 155, 156, 157, 158, 161,
162, 163, 164, 165, 166, 167, 168,
171, 172, 173, 174, 175, 176, 177,
178, 181, 182, 183, 184, 185, 186,
187, 188
011 – Stop
E3.62 Stage 1 action 011 – Stop
E3.64 Stage 2 action 011 – Stop
E3.66 Stage 3 action 011 – Stop
E3.68 Stage 4 action 011 – Stop
E3.70 Stage 5 action 011 – Stop
E3.72 Stage 6 action 011 – Stop
E3.74 Stage 7 action 011 – Stop
E3.76 Stage 8 action 011 – Stop
E3.78 Stage 9 action 011 – Stop
E3.80 Stage 10 action 011 – Stop
E3.82 Stage 11 action 011 – Stop
E3.84 Stage 12 action 011 – Stop
E3.86 Stage 13 action 011 – Stop
E3.88 Stage 14 action 011 – Stop
E3.90 Stage 15 action 011 – Stop
E0.26 Acceleration time 0.1...6,000.0 s DOM 0.1 Run
E0.27 Deceleration time 0.1...6,000.0 s DOM 0.1 Run
E3.10 Acceleration time 2 0.1...6,000.0 s 10.0 0.1 Run
E3.11 Deceleration time 2 0.1...6,000.0 s 10.0 0.1 Run
E3.12 Acceleration time 3 0.1...6,000.0 s 10.0 0.1 Run
E3.13 Deceleration time 3 0.1...6,000.0 s 10.0 0.1 Run
E3.14 Acceleration time 4 0.1...6,000.0 s 10.0 0.1 Run
E3.15 Deceleration time 4 0.1...6,000.0 s 10.0 0.1 Run
E3.16 Acceleration time 5 0.1...6,000.0 s 10.0 0.1 Run
E3.17 Deceleration time 5 0.1...6,000.0 s 10.0 0.1 Run
E3.18 Acceleration time 6 0.1...6,000.0 s 10.0 0.1 Run
E3.19 Deceleration time 6 0.1...6,000.0 s 10.0 0.1 Run
E3.20 Acceleration time 7 0.1...6,000.0 s 10.0 0.1 Run
E3.21 Deceleration time 7 0.1...6,000.0 s 10.0 0.1 Run
E3.22 Acceleration time 8 0.1...6,000.0 s 10.0 0.1 Run
E3.23 Deceleration time 8 0.1...6,000.0 s 10.0 0.1 Run
The digit definition for each stage action is as the figure below:
Bosch Rexroth AG
Functions and Parameters
EFC x610 Series
138/389
DOK-RCON03-EFC-X610***-IT05-EN-P
