15 February 2006 COPY CONNECTOR KITS
1-123
Installation
8. Lead the interface cable [AI] through the anti-static cap [BJ], and then connect
it to the interface board.
9. Attach the anti-static cap (2 knob screws [C]).
10. Replace the key top [D].
11. Repeat both the firmware and hardware procedures above for the other copier.
B110I204_RTB.WMF
B110I103_RTB.WMF
[A]
[B]
[C]
[D]
