FUSING UNIT
15 February 2006
3-74
[A]: Plate
(
x 1)
[B]:
W
hite connector (
x 1)
[C]:
Red connectors (
x 2)
[D]:
Front fusing lamp holder (
x 1)
[E]:
Fusing lamps (x
3)
NOTE:
Be careful when you mov
e the fusing lamps. Do not break them. Do not
touch them with bar
e hands.
B246R1006.WMF
B140 Series Front
[A]
[B]
[C]
[D]
[E]
302
304
