15 February 2006 B140/B246 SERIES SERVICE MODE
4-67
Trouble-
shooting
SC No. Symptom Possible Cause
Self-diagnostic error 2: ASIC
The ASIC provides the central point for the control of bus arbitration for CPU
access, for option bus and SDRAM access, for SDRAM refresh, and for
management of the internal bus gate.
0B0
0
Error code 0xffff ffff is
returned when the register
Write & Verify check is
executed on the ASIC
mounted on the controller
board. The ASIC controls
the ROM and buses for
other devices.
• ASIC (controller board defective)
0B0
6
ASIC not detected
• ASIC defective
• Poor connection between North Bridge
and PCI I/F
• Replace controller board
821 D
0B1
0
Failed to initialize or could
not read connection bus.
Data in SHM register
incorrect.
• Connection bus defective
• SHM defective
• Replace controller board
NOTE: For more details about this SC code error, execute SP5990 to print an SMC
report so you can read the error code. The error code is not displayed on the
operation panel.
SC No. Symptom Possible Cause
822 B Self-diagnostic error 3: HDD
3003
Check performed when HDD
is installed:
• HDD device busy for over
31 s.
• After a diagnostic
command is set for Sthe
HDD, but the device
remains busy for over 6 s.
A diagnostic command is
issued to the HDD device but
the result is an erro
• HDD defective
• HDD harness disconnected, defective
• Controller board defective
3004
No response to the self-
diagnostic command from the
ASIC to the HDDs
• HDD defective
3013
Mandolin does not respond,
the HDD device remains
BUSY for more than 31 s, or
the BUSY signal does not
drop within 6 s after the
diagnostic command is
issued to the HDDs.
• HDD defective
• HDD connector loose or defective
• Controller defective
To Next Page
