15 February 2006 SERVICE PROGRAM MODE TABLES
5-33
Service
Tables
1902* Fusing Web Motor Control
001 Fusing Web Used Area Display/Setting
Displays the percentage of the web consumption in 1% steps (0% ~ 100%). This
setting must be reset to zero after the web is replaced.
[0~120/1 %]
002 Fusing Web Motor Operation Interval
Adjusts the interval of copy operation time (seconds) after which the web motor is
driven.
[5~50/1 s]
003 Fusing Web Motor Operation Time
Adjusts the length of time that the web motor is driven.
[1~40/0.1 s]
004 Web Near End Value
Adjusts the timing of the web near end alert by changing the amount of web that
has been used before the alert is triggered.
[0~100/1 %]
005 Web Roll Coefficient
Determines the coefficient of the web take-up time from cleaning toner from the
roller while taking into consideration the take-up time for web buckle. DFU
[10~20/1]
1903* Web Job End
001 Yes/No
This determines whether the web motor is driven at the end of a job.
[0~1/1]
0: Off
1: On
Enable when too much paper dust is causing copies to blacken.
002 Job End Condition (Continuous PPC Time)
At the end of a job, the web motor is driven if the job lasted longer than the value of
this SP mode. Only valid if SP1903-001 is set to ‘On’.
[1~99/1s]
003 Job End Frequency
If the web motor is driven at the end of a job, this SP determines how many times
the web motor operation is executed.
[1~5/1]
1904 By-pass Tray Paper Size Correction
001 Minimum Size
Calibrates the minimum paper width position of the sensor (100 mm). Move the
side fences to the 100 mm position then press Execute.
002 Maximum Size
Calibrates the maximum paper width position of the sensor (A3). Move the side
fences to the A3 position then press Execute.
