SERVICE PROGRAM MODE TABLES 15 February 2006
5-120
6007 ADF Input Check
Displays signals received from sensors and switches in the ADF. (☛ 5.6.3)
001 Group 1
002 Group 2
003 Group 3
6008 ADF Output Check
Turns on the ADF electrical components individually for testing. (☛ 5.6.4)
001 Feed Motor: Forward
002 Feed Motor: Reverse
003 Transport Motor: Forward
004 Exit Motor: Forward
005 Pick-up Motor: Reverse
006 Bottom Plate Motor: Forward
007 Bottom Plate Motor: Reverse
6009 DF Free Run Performs an ADF free run in duplex original mode.
6016 Original Size Determination Priority
Allows selection of alternate settings for automatic original size detection. (☛6.4.8)
6017* Sheet Through Magnification
This changes the magnification by adjusting the speed of scanning.
[–50~+50/1 %]
6020* ADF Contact Mode In/Out
If the original is small (B6, A5, HLT), the delay sensor detects the leading edge of
the sheet and delays the original at the entrance roller for the prescribed number
of pulses to buckle the leading edge and correct skew.
[0~1/1]
0: Delay skew correction only for small originals
1: Delay skew correction for all originals, regardless of size. (May reduce the
scanning speed of the ADF)
