15 February 2006 SERVICE PROGRAM MODE TABLES
5-143
Service
Tables
7507* Plotter Jam History
001 Copy Latest
002 Latest 1
003 Latest 2
004 Latest 3
005 Latest 4
006 Latest 5
007 Latest 6
008 Latest 7
009 Latest 8
010 Latest 9
Displays the copy jam history (the most recent 10 jams)
Sample Display:
CODE:007
SIZE:05h
TOTAL:0000334
DATE:Mon Mar 15 11:44:50 2000
where:
CODE is the SP7504-* number (see above.
SIZE is the ASAP paper size code in hex.
TOTAL is the total jam error count (SP7003)
DATE is the date the jams occurred.
Size Code Size Code Size Code
A4 (S) 05 A3 (L) 84 DLT (L) A0
A5 (S) 06 A4 (L) 85 LG (L) A4
B5 (S) 0E A5 (L) 86 LT (L) A6
LT (S) 26 B4 (L) 8D HLT (L) AC
HLT (S) 2C B5 (L) 8E Others FF
Original Jam History
7508
Displays the original jam history of the transfer unit in groups of 10, starting with
the most recent 10 jams. Display contents are as follows:
CODE is the SP7-505-*** number.
SIZE is the paper size code in hex. (See “Paper Size Hex Codes” below.)
TOTAL is the total jam error count (SP7-003)
DATE is the date the previous jam occurred
Sample Display:
CODE: 007
SIZE: 05h
TOTAL: 0000334
DATE: Mon Mar 15 11:44:50 2000
Paper Size Hex Codes
These codes are displayed by SP7507 and SP7508.
Paper Size Code (hex) Paper Size Code (hex)
A4 LEF 05 B4 SEF 8D
A5 LEF 06 B5 SEF 8E
B5 LEF 0E DLT SEF A0
LT LEF 26 LG SEF A4
HLT LEF 2C LT SEF A6
A3 SEF 84 HLT SEF AC
A4 SEF 85 Others FF
A5 SEF 86
