Ricoh MT-C1 User Manual

INPUT/OUTPUT CHECK 15 February 2006
5-190
1500 sheets 1000 sheets 400 sheets 70 sheets
bit-3 0 0 0 0 0 0 1 1
bit-2 0 0 0 1 1 1 1 0
bit-1 0 0 1 1 1 0 0 0
bit-0 0 1 1 0 0 0 0 0
3. Paper Feed 3
Reading
Bit Description
0 0
7 3rd Paper Size Switch
6 3rd Paper Size Switch
5 3rd Paper Size Switch
4 3rd Paper Size Switch
3 3rd Paper Size Switch
2 Not used
1 Not used
0 Not used
See Paper Size Tables Below.
Universal Tray Size Detection – N.A. models only
Paper Size Switch Setting (LOW = pressed) Panel Display
11" x 17" LOW HIGH HIGH HIGH HIGH 11" x 17" SEF
81/2" x 14" LOW LOW HIGH HIGH HIGH 81/2" x 14" SEF
81/2" x 11" HIGH LOW LOW HIGH HIGH 81/2" x 11" SEF
11" x 8 ½" LOW HIGH LOW LOW HIGH 81/2" x 11" LEF
51/2" x 81/2" LOW LOW HIGH LOW LOW 51/2" x 81/2" SEF
81/2" x 51/2" LOW LOW LOW HIGH LOW 81/2" x 51/2" LEF
8" x 101/2" LOW LOW LOW LOW HIGH 8" x 101/2" SEF
7¼" x 101/2" HIGH LOW LOW LOW LOW 71/4" x 101/2" SEF
8" x 13" HIGH HIGH LOW LOW LOW 8" x 13" SEF
* HIGH HIGH HIGH HIGH LOW (size set in User
Tools)
Universal Tray Size Detection – EU/ASIA models
Paper Size Switch Setting (LOW = pressed) Panel Display
A3 SEF LOW HIGH HIGH HIGH HIGH A3 SEF
81/4" x 13" LOW LOW HIGH HIGH HIGH 81/4" x 13" SEF
A4 SEF HIGH LOW LOW HIGH HIGH A4 SEF
A4 LEF LOW HIGH LOW LOW HIGH A4 LEF
81/2" x 13" LOW LOW HIGH LOW LOW 81/2" x 13" SEF
A5 SEF LOW LOW LOW HIGH LOW A5 SEF
A5 LEF LOW LOW LOW LOW HIGH A5 LEF
* HIGH HIGH HIGH HIGH LOW (Size set in User
Tools)
