Maintenance and Service
Hydraulic system
(5) Specialized tool
(6) Rotation direction mark
Using the special tool
(ROPA item no. 018139800) (5), turn the
new filter element clockwise in the direc-
tion of the "CLOSE" marking (6) until a
slight resistance is felt.
After you feel some resistance, turn a lit-
tle further clockwise until a greater resis-
tance is felt.
(8) Ball joint in the filter element can
be swivelled, element tilted to
the side
Now the ball joint integrated in the fil-
ter element can be swivelled and the fil-
ter element can be tilted sideways in the
housing (8). In this way, tolerances in the
housing are compensated.
Tightening torque of the filter element:
8 Nm.
Then position the filter element centrally
to the housing.
