[RFID]
214
Count Total
Shows the total number of times you have written to an RFID tag after the RFID counter is
cleared.
This is the total number including [Count Success] and [Count Failure].
• You can reset the counter by tapping [Clear Counters] when the counter is 1 or higher.
[Paper]
Set the print reference position in the vertical direction for RFID tags.
The setting item is as follows:
[Starting Point]
Set the print reference position in the vertical direction for RFID tags.
Set the print reference position by using '+' to move in the feed direction and '-' to move opposite to the
feed direction.
The setting range is from -200 to +200 dots.
• The length of 1 dot varies depending on the print resolution of the product.
â—¦ 203 dpi : 1 dot = 0.125 mm (0.0049")
â—¦ 305 dpi : 1 dot = 0.083 mm (0.0033")
• You can change the units to dots, " (inches), or mm in the [System] > [Regional] >
[Unit] menu.
[SATO RF Analyze]
Set and execute the SATO RF Analyze function, and save the results of the measurements. SATO RF
Analyze is a function of the product that allows you to measure RFID tags and easily set conditions to
consistently write and read them.
The setting items are as follows:
[Search Start]
Execute SATO RF Analyze.
Set the measurement conditions as needed in [Search Level], [Write Power], [Read Power], and [Save
settings] before executing.
Load RFID tags into the product, and tap [Search Start]. Measurement of the RFID tag starts, and the
state of the measurement appears on the screen. Complete the measurement according to the on-
screen instructions.
• The length from the leading edge of the tag to the inlay should be 15 mm (0.59") or
more.
• The tag length should be 42 mm (1.65") or more (including liner) to execute SATO RF
Analyze.
