For SYNTH2 type patterns, CV/Gate output pair 1 produces CV and Gate signals for
pitch 1, output pair 2 produces accent and velocity signals for pitch 1. CV/Gate output
pair 3 produces CV and Gate signals for pitch 2, output pair 4 produces accent and
velocity signals for pitch 2, and so forth for the pitches 3 and 4.
For DRUM type patterns, each of the eight group 1 drum instruments have a dedicated
CV/Gate output pair. The outputs produce triggers from the GATE/TRIG outputs and
accent triggers from the CV/VEL outputs.
