GLOBAL CONFIG
For CONTROL type patterns, CV/Gate outputs 1 through 6 output CV and Gate signals
that correspond to the six controls. CV output 7 produces a voltage that corresponds to
the TEMPO knob location.
 USER GUIDE 206
ENGINE CV OUTPUT EXPANSION
CTRL TYPE PATTERN
TEMPO CV
CTRL 6 CV
CTRL 5 CV
CTRL 4 CV
CTRL 3 CV
CTRL 2 CV
CTRL 1 CV
CTRL 6 GATE
CTRL 1 GATE
CTRL 2 GATE
CTRL 3 GATE
CTRL 4 GATE
CTRL 5 GATE
