OnAir 3000 Digital Mixing Console
Operation 5-59
Document generated: 10.10.14
SW V6.0
The number of processes and assignable channels can be defined in the
Config.xml file. The OnAir 3000 allows a number of one to four VMix
processes with 6 to 24 assignable members (or 32 assignable members for
configs C6, C8 and C109 ) .
Cue/PFL Also in the configuration tool, the cue mode (alternative to pfl mode) can be
chosen to be “Pre” or “After” VoiceMix processing. For selecting these cue
modes, please see chapter 6.5.14.
User Access Privilege For access to VMix parameters, privileges may be defined within a policy.
see chapter 5.10.7.
Rotary assign functions VMix assign On/Off as well as the Weight parameter can be configured to be
used on the rotary module - see chapter 6.5.37.3
Desk_KeyMapping.xml A global VMix On/Off button for every VoiceMix process can be configured
on the desk surface. This is done in the file Desk_KeyMapping.xml.
See the table ‘Assignable Global Functions’ in chapter 6.5.37.4.
On the VoiceMix page, labels and control elements of all (maximum) four
VoiceMix processes are displayed.
Clear All The ‘Clear-All’ button releases all channels previousily assigned to this
VoiceMix process.
‘Clear-All’ also clears assigments of Logical Inputs which are currently not
on a fader.
Underneath it, the number of processed and assigned channels is shown. (With
the default configuration, each VoiceMix process can process a maximal
number of eight channels).
Processed : The number of Logical Inputs currently processed by a VoiceMix process.
Assigned : The number of Logical Inputs assigned to a Voice Mix process.
This includes also Logical Inputs, which are currently not on a fader.
ON The ‘On’ button activates the VMix processing for each of the four VoiceMix
