Studer OnAir 3000 User Manual

OnAir 3000 Digital Mixing Console
5-82 Operation
Document generated: 10.10.14
SW V6.0
ROOM source selector. PFL TO MON is illuminated if active.
ADD Function The ADD function is very handy for a station takeover. It allows temporarily
selecting two sources for the CR monitoring. The second source is temporar-
ily added by pressing ADD, and, while ADD is illuminated, selecting a second
source. Now both sources are either mixed together or sent to the left/right
monitor channels (configurable); ADD will be dark, but the source selector
keys of both active sources will be illuminated.
The ADD function is canceled automatically when selecting the next source.
LSP Split Mode If enabled in the Configuration Tool (see chapter 6.5.24.1, it can be activated/
deactivated for CR and Studio 1 individually), this mode enables the CR or
ST1 LSP signal to be split depending on the HP Split Mode in a similar way
as for the headphones.
With PFL TO MON not active, the LSP Split mode does not affect the CR/ST1
monitor speakers at all.
With PFL TO MON active, PFL and the PFL / MON button or the HP Split Mode
selector in the UserGUI, see chapter 5.3.4.3, affects the CR/ST1 monitor
speakers as follows :
MON CR/ST1 monitor speakers provide the stereo/5.1 signal selected by the source
selector as long as no PFL is active. Otherwise, the stereo SP SRC
*
signal is
fed to the CR/ST1 monitor speakers.
PFL / MON Activating PFL on any channel provides two mono signals to the CR/ST1
(or SP SRC / MON in the UserGUI) monitor speakers. The left
**
loudspeaker signal is the mono SP SRC
*
signal,
while the right
**
one is a mono mix of the CR/ST1 monitor signal as selected
for the CR/ST1 monitor speakers by the source selector. If the SP SRC
*
signal
is the same as the CR/ST1 monitor signal or no PFL is active, the CR/ST1
monitor speaker signal is the stereo/5.1 CR/ST1 monitor signal as if MON
were active (see above).
PFL (or SP SRC in the UserGUI) Sames as MON
The LSP Signal is according to the following table: :
LSP (LSPSplitEnable = active)
PFL To Mon HP Split Mode Signal when PFL is
not active
Signal when PFL is
active
OFF MON ST/5.1 MON ST/5.1 MON
OFF PFL ST/5.1 MON ST/5.1 MON
OFF PFL/MON ST/5.1 MON ST/5.1 MON
ON MON ST/5.1 MON ST SP SRC*
ON PFL ST/5.1 MON ST SP SRC*
ON PFL/MON ST/5.1 MON M SP SRC*/ M MON **
*
The SP SRC signal is PFL, if PFL is active on any channel and CR/ST1 PFL
to SP SRC is enabled in the Configuration Tool otherwise it is the selected
SP SRC.
**
There is also a possibility to swap the two signals, so that the SP SRC signal
is in the right channel, see chapter 6.5.24.1.
Internal Speaker The PFL, talkback return, and MPX master signals are mixed and fed in mono
to the built-in speaker.
