OnAir Digital Mixing Consoles
6-32  Conguration
Document generated: 10.10.14
SW V6.0
British Standard Peak Audio Level Can be selected in steps of 1 dB within a range of –48 to 0 dB
FS
(default value:
–10 dB
FS
.
  British Standard M/S Mode  Level reduction of the M meter can be selected from either –3 dB or –6 dB
(default value: –3 dB).
ChannelOn follows FaderOpen If active, this function automatically switches a channel ON while its fader
is open. Selections: On or Off, default value: Off.
VCA ChannelOn Control, VCA Channel PFL Control
These settings are used to activate the ON and PFL functions for VCA mem-
bers (usually, only the VCA master fader effects the VCA members). Only
available if the VCA option is licensed and activated. Selections: On or Off,
default value: Off.
OnAir 1500/2500: Not supported.
Generator off for on-air channels If set to On, this function disables the GEN button on the channel pages for
all channels currently being on-air; default value: Off.
Reset Timer On Fader Close If set to On, cumulative time measurement is selected for the input fader
stopwatches; a running stopwatch is stopped by switching the channel OFF; it
is reset only when the fader is closed; default value: Off. Also refer to chapter
5.9.
Channel TB Selections: Nothing, or TB Off on Channel Active, default value: Nothing.
If TB Off on Channel Active is selected, talkback to a channel currently
being active is inhibited.
5.1 to Stereo Mixdown...  Sets the contribution level of surround and center channels for the internal
stereo downmix, as well as the overall level.
Surround Level Adjustable in steps of 1 dB between 0 and –10 dB; default setting: –3 dB.
Center Level Adjustable in steps of 1 dB between 0 and –10 dB; default setting: –3 dB.
Trim Level Adjustable in steps of 1 dB between 0 and –10 dB; default setting: 0 dB.
OnAir 1500/2500: 5.1-channel outputs not supported.
Mono Mode Selects(L+R)–3dB(M3mode)or(L+R)–6dB(M6 mode) for mono mixes
of stereo sources.
