OnAir Digital Mixing Consoles
6-150 Conguration
Document generated: 10.10.14
SW V6.0
connections.
By default, the OnAir application software controls Input Stream Patching
on all Listeners of an AoIP Card. Optionally, Listeners can be excluded from
OnAir application software Stream Patching.
Therefore, a list Listeners can be specified as DisablePatchControl in the
Connector section.
Example to avoid Stream Patching by the OnAir application software to
Listeners 1,2,3 and 8:
<DisablePatchControl>
<Listener Num=”1”/>
<Listener Num=”2”/>
<Listener Num=”3”/>
<Listener Num=”8”/>
</DisablePatchControl>
Input Stream 1
LVDS In 1
LVDS In 2
Input Stream 8
LVDS In 15
LVDS In 16
LogicalInput A
FRouter51Src.FirstSource
FRouter51Src.SecondSource
Physical Input Mapping
Listener 1
Listener 8
Input Stream Patching
6.6.2.1.3 Disable Stream Name Control
Disable Stream Name Control avoids conflicts when external software like
the Axia PathFinder is used or Livewire cards are used for static tie lines.
Disable Stream Name Control prevents the OnAir application software from
setting the name of the specified Output Stream.
By default, the OnAir application software controls the name of all Output
Streams of an AoIP Card. Optionally, Talkers can be excluded from OnAir
application software control.
Therefore, a list Talker can be specified as DisableStreamNameControl in the
Connector section.
Example to avoid StreamName Control by the OnAir application software
for the Talkers 1 and 2:
<DisableStreamNameControl>
<Talker Num=”1”/>
<Talker Num=”2”/>
</ DisableStreamNameControl >
