OnAir 3000 Digital Mixing Console
4-14 Operating Elements
Document generated: 10.10.14
SW V6.0
Input channel routing can also be described with the diagram below :
LockedNormal
InputSelect
GroupSelect
short press
touch
activate selector
short press
select input / exit
lock
set to locked
unlock
set to normal
lock
set to locked
operation
timeout
exit
long press
exit
long press
back to group selector
level down level up / exit lock / unlock
StripAssign
change
exit
to input selector
AoIP-stream input routing Assigning an AoIP-stream to the current fader channel can also be done
directly on the desk surface.
The following diagram describes the different levels of the input selector. In
general, a short pressure on the rotary button changes to the next level and
a long pressure changes to the previous level.
