Studer OnAir 3000 User Manual

OnAir 3000 Digital Mixing Console
4-16 Operating Elements
Document generated: 10.10.14
SW V6.0
Level 2: Input Group Selector The Input Group Selector provides the Input Groups as configured for the
console. If the current assigned input provides Stream Patching and is not
on-air, the first item of the Input Group List is a direct access to the Stream
Group Selector. This will be indicated with the name “Sources” in the 2nd
label area.
A short pressure on the rotary button changes to the selected Input Group or
in case of “Sources” to the Stream Group Selector.
  • SelectionforInputswithoutStreamPatchControl:
[InputGroupA] [InputGroupB] [InputGroupC] …
  • SelectionforInputswithStreamPatchControl:
[“Sources”] [InputGroupA] [InputGroupB] [InputGroupC] …
Level 3: Input Selector The Input Selector provides the inputs as configured for the selected Input
Group. The following assignments are possible:
  • StateofcurrentassignedInputis‘on-air’.Allinputswhicharealready
assigned to an unlocked strip (only swapping is allowed).
  • StateofcurrentassignedInputisnot‘on-air.’Allinputswhicharenot
currently assigned to a locked strip.
The Input assignment will be applied by a short pressure on the rotary button.
If the new assigned input provides Stream Patching, the Input Selector
changes to the Stream Group Selector.
Level 4: Stream Group Selector The Stream Group Selector provides all currently available Stream Groups.
The first item of the Stream Group List is a direct access to the clear source
function marked as “None”.
  • StreamGroupSelection:
[“None”] [StreamGroupA] [StreamGroupB] [StreamGroupC] …
If one enters into the Stream Group Selector from a lower level, the current
selected item is the first stream group (StreamGroupA). If one enters from a
higher level, the current selected item will be the last selected stream group.
In case of a selected Stream Group a short pressure on the rotary button
changes to the Stream Selector, ‘Clear Source’ closes the Input Selector.
Level 5: Stream Selector The Stream Selector provides all currently available streams of the selected
group. The first item of the Stream List is a direct access to the clear source
function marked as “None”.
  • StreamSelecton:
[“None”] [StreamA] [StreamB] [StreamC] …
Upon entering the Stream Selector, always the first stream (StreamA) is
selected.
