Altera Corporation 12–17
September 2004 Stratix Device Handbook, Volume 2
Remote System Configuration with Stratix & Stratix GX Devices
Remote Update WYSIWYG ATOM
An alternative to using the altremote_update megafunction is to
directly instantiate the remote update WYSIWYG atom. This atom should
be included in the factory configuration and any application
configuration image to access the remote configuration shift registers.
When implementing the atom, you should consider following:
1. Only one atom can be used in the circuit; more than one gives a
no-fit.
2. All signals for the cell must be connected. The clock port (CLK) must
be connected to a live cell. The others can be constant V
CC
or GND.
3. The pgmout port must be connected and must feed PGM[2.0]
output pins (it cannot be connected to anything else but output
pins).
4. The Quartus II software reserves RUnLU as an input pin, and you
must connect it to V
CC
.
Page select 100 3 3 bit '001' - Local
configuration
Page mode selection. Writing of this parameter
is only allowed when in the factory
configuration.
3 bit '000' -
Remote
configuration
Current
configuration
(AnF)
101 1 1 bit '0' - Factory Specifies whether the current configuration is
factory or and application configuration. This
parameter can only be read.
1 bit '1' -
Application
Illegal values 001
110
111
Table 12–8. Parameter Settings for the altremote_update Megafunction (Part 2 of 2)
Selected
Parameter
param[2..0]
bit setting
width of
parameter
value
POR Reset
Value
Description
