Altera Corporation Section VII–1
Section VII. PCB Layout
Guidelines
This section provides information for board layout designers to
successfully layout their boards for Stratix
®
devices. This section contains
the required PCB layout guidelines and package specifications.
This section contains the following chapters:
■ Chapter 13, Package Information for Stratix Devices
■ Chapter 14, Designing with 1.5-V Devices
Revision History
The table below shows the revision history for Chapters 13 and 14.
Chapter Date/Version Changes Made
13 July 2005, v3.0 Updated packaging information.
September 2004, v2.1
● Changed from Chapter 8, Volume 3 to Chapter 13, Volume 2.
● Corrected spelling error.
April 2003, v1.0
● No new changes in Stratix Device Handbook v2.0.
14 January 2005, v1.2
● This chapter was formerly chapter 15.
September 2004, v1.1
● Changed from Chapter 10, Volume 3 to Chapter 15, Volume 2.
● Corrected spelling error.
April 2003, v1.0
● No new changes in Stratix Device Handbook v2.0.
