Compulite Spark User Manual

Assigning Editor Groups
Spark
12-7
Assigning a channel with a specified intensity
Example: assign channel 1 at 45% and channels 3 - 8 at 50% to controller 7.
Keypresses Results/Comments
1. Select channel 1.
2. Press [@4.5 or use the
dimmer wheel
3. Select channels 3 Æ 8
4. Press [ON]
The editor now contains channel 1 @ 45 and
channels 3 Æ 8 @ 50. (Access [ON] with
[SHIFT])
5.
Press [ASSIGN]
The message
Assign Key Expected is displayed.
6. Press controller 7’s SK. When controller 7 is raised to its upper limit
channel 1 is output at 45% and channels 3 Æ 8
at 50%.
Assigning a range of channels to sequential controllers
Example: Assign channel 40 to controller 8, channel 41 to controller 9, channel 42 to
controller 10, channel 43 to controller 11, until all the controllers from 8 to controller 20
have single channels assignments.
Keypresses Results/Comments
1. Select channel 40
2. Press [ Æ
Æ
]
3.
Press [ASSIGN]
The message
Assign Key Expected is displayed.
4. Press controller 8’s SK. Channel 40 is assigned to controller 8, channel 41
to controller 9, channel 42 to controller 10, etc.
Grp
is shown on the controller display.
