The Mix Output Menu
Spark
21-12
3. DMX is set to control channel according to specifications and time is set to any value
except 99. The default or selected value is transmitted; the duration of the
transmission is determined by the time value.
It is illegal to assign 99 to both DMX and time.
Example 1: DMX set at 99. Most Clay Paky devices use this definition to reset the lights.
Contr DMX Time Value
Ignite 99 6 0
Example 2: DMX is set according to manufacturer's specifications and the time is set to
99. In this case the default value or a selected value is sent indefinitely until a new ignition
command is transmitted.
Contr DMX Time Value
Ignite 12 99 0
Example 3: DMX is set according to manufacturer's specifications and time is set from 1
up to and including 14. Setting the time to more than 14 results in an illegal number
message. The default or selected value is transmitted; the duration of the transmission is
determined by the time value. This definition is used for the NATs and Summa. When
sending the ignition, enter 0 for lamp off, 1 for lamp on, 2 for reset.
Contr DMX Time Value
ignite 12 6 0
Editing parameter wheels assignments
This function permits you to assign parameters to the wheels in any order desired. The
display for the Param To Wheels function (F1) consists of the Wheels window showing 3
wheels, Wheel 1 being the bottom wheel. Each wheel has 9 banks. The parameter window
displays the parameter names of the selected spot. Parameters may be assigned to 1 or
more wheel bank. A color code shows the assignment status of each parameter:
Color Wheel assignment status
White selected
Gray no wheel assignment for parameter
Blue parameter assigned to one wheel bank
Brown parameter assigned to more than one wheel bank
To Next Page
