Configuring the number of frames
The default is 12 frames per second.
Keypresses Results/Comments
1. In Service Tools/Config Sys,
Press F5 Special Numbers.
The Special Numbers are displayed.
2. Select SMPTE frames per
second.
3. Enter a number from 12 – 50.
4. Press F6 Enter & Exit
The main Config Sys menu is displayed.
5. Press F6 Store config to
confirm the save command.
6. Press F1 Cold Start
Teaching SMPTE Time
SMPTE codes are assigned to Events that have been programmed in the Event menu (see
Chapter 12 Event).
The “teach” function can be used to assign time codes to Events only when the Event has
no previous SMPTE assignment. If a time assignment is present it must be erased.
Access the [SMPTE] key using [SHIFT].
Keypresses Results/Comments
1. Press [SMPTE]
The options available on the F keys are displayed in
the command line area.
2. Press F2 Teach Me
Notice that in the upper right corner of the display,
the first event number and the current time on the
SMPTE generator are displayed.
3. Start the SMPTE
generating device
The time code starts running and is displayed at the
top of the monitor.
4. Press F1 Store Event
when the time code for
this Event is displayed.
The system automatically advances to the next
event number.
