Teaching SMPTE Time
Spark
23-
4
Starting at a selected Event
Example: You have already assigned time codes to Events 1 – 4. Teach SMPTE time codes
starting from Event 5.
F1 Store Event is operational only when it becomes viable. Example: Event 1 has an
SMPTE assignment of 00.00.51.02. Event 2 SMPTE assignment is 00.01.03.15. Event 3
has no assignment. If the SMPTE code starts running from 00.00.00.00 (and Event 3 is
selected), only when Event 2 has been triggered will the system allow the F1 Store Event
option for event 3.
Keypresses Results/Comments
1. Press [EVENT]
The console prompts for an Event number.
2. Enter the event number
on the numeric keypad.
3. Press SMPTE
The function keys are displayed in the command
line area.
4. Press F2 Teach Me
5. Start the SMPTE
generating device
The time code starts running and is displayed at the
top of the monitor.
6. Press F1 Store Event
when the time code for
this Event is displayed.
The system automatically advances to the next
event number.
Exiting the teach function
Keypresses Results/Comments
1. Press SMPTE
2. Press F3 OFF
The system stops 'listening' to the SMPTE generator.
