Compulite Spark User Manual

The DMX Input patch
Spark
24-5
Example: Return channels .55 Æ 57 to the default
Keypresses Results/Comments
1. Press F3 Default (1 to 1)
2. Press F2 Channels
Spark prompts for a channel number.
3. Enter 55 on the numeric
keypad.
4. Press F1 Thru Channel
and enter 57 on the keypad
or
Press [ Æ
Æ
] and enter 57 on
the keypad.
5. Press F3 Store
The selected channels return to default.
Examining DMX input assignments
Isolate selected input channels for examination.
Keypresses Results/Comments
1. Press F5 Exam
Spark prompts:
Exam assignment of input #:
2. Enter the input number on
the numeric keypad.
3. Press F1 Enter
The patch assignments for the selected input
channel are displayed.
4. Press or F1 Previous or
F2 Next or [-] [+] to
continuing.
Assigning macros to DMX input
One macro can be assigned to an input channel.
When a macro is assigned, raising the intensity level of the input channel operates the
macro. The default execution threshold is 50%. The execution threshold can be changed in
the Assign Input option in the Macro menu.
Keypresses Results/Comments
1. Go to the Macro menu.
2. Press F5 Assign Input
The input patch table is displayed.
3. Enter a macro number. Spark prompts for an Input channel number.
4. Enter an input channel.
5. Optional - Press F2 Start
From and enter a level.
The default level assignment is 50%.
6. Press F1 Store
