Programming Memories with Parts
Spark
15-4
Programming Parts with scrollers
Scrollers work in Part assignments only when the System parameters toggle Scrl jump on
fade is toggled to No (see Chapter 20 System Configuration)
Example: Program memory 2 and assign channels 1
Æ
5 at frame 6 to part 2.
Keypresses Results/Comments
1. Select channels 1
Æ
5.
2. Press [FRAME]
The scroller flag is displayed in red.
3. Assign frame 6
4. Press [PART] and enter 2 on the
numeric keypad.
The scroller frame is displayed in light
gray - the color code for part 2.
5. Press [TIME] and enter 3 on the
numeric keypad.
Assign an up fade time of 3 to part 1.
6. Press [WAIT] and enter 2 on the
numeric keypad.
Assign a wait time: the amount of time
part 1 will wait before beginning its fade.
7. Press [=] and enter 2 on the
numeric keypad.
8. Press [STORE]
The message
Memory 2 Stored
is
displayed.
Programming Parts with spots
Example: Assign spots 1 - 5, in their entirety, to part 1.
Keypresses Results/Comments
1. Select spots 1
Æ
5 and assign
parameter values.
2. Press [ALL]
All parameters in the selected spots are
displayed in red.
3. Press [PART] and enter 1 on the
numeric keypad.
A green dash is displayed next to all
parameter values in the selected spots.
4. Press [TIME] and enter 3 on the
numeric keypad.
5. Press [WAIT] and enter 2 on the
numeric keypad.
6. Press [=] and enter 1 on the
numeric keypad.
7. Press [STORE]
The message
Memory 1 Stored
is
displayed.
