The Editor Section
Spark
2-3
F keys
The Function (F) keys are multi-purpose soft keys, generally used while working in
menus. When the system is not in menu mode, F1-F5 offer immediate access to macros 1-
5. F6 accesses all the rest of the macros. In menu mode these keys access the convenient
menu functions and options. These keys are also used for Delta application and editing
SMPTE time codes.
Programming memories
Memories are programmed by selecting channels and assigning intensity values or
selecting spots and assigning parameter values, then storing the resulting stage picture.
Each memory may be programmed for the following information:
• Fade in and out time, from 'cut' to 999.9 seconds.
• Delay, wait -in, and wait out time, from 'cut' to 999.9 seconds.
• An automatic follow-on memory created by using the loop function.
• Loops containing any number of memories.
• Links between non-sequential memories.
• Event assignments that automatically operate multiple functions
• Parts
• Text
Editor color key
Color Status
Red field Spots and channels selected in the editor. Spots and channels
displayed in red can be assigned intensity levels and parameter values.
White field Spots and channels that are present in the editor. When storing an
editor group as a memory the spots and channels displayed in white
and red are included in the memory.
Dark blue Spots and channels selected under memory modification (see Chapter
9 Modifying Memories).
