4
© 06/2006 8145-001
22/28
TCD 2015
Technical data
Tightening specifications
A07 015 Fuel pipe to injection pump housing
TCD 2015 25 Nm
TCD 2015
(Railway)
25 Nm
A07 018 Fuel pipe to fuel shut-off valve (flame flow plugs) Union nut TCD 2015 20 Nm
A07 023 Temperature transmitter on connector TCD 2015 22 Nm
A07 024
Bearing housing (fuel supply pump) to genset
support
TCD 2015 42 Nm
A07 034 Fuel line on fuel supply pump Hollow screw TCD 2015 max.35 Nm
A07 044
Fuel pipe fastening
Pipe clamp/holder
oil thread and head contact
surface.
TCD 2015 8.5 Nm
Fuel pipe fastening Pipe clamp
TCD 2015
(Railway)
8.5 Nm
A07 057 Adapter (flame glow plug) on charge air pipe M45x1.5 SW50
TCD 2015
(Railway)
50 Nm
A07 058 Ground cable on lock nut (flame glow plug)
TCD 2015
(Railway)
7.5 Nm
A07 059 Flame glow plug to connecting pipe Lock nut TCD 2015 25 Nm
A07 066
Connector (fuel pressure holding valve) to fuel
pipe
Union nut
TCD 2015 42 Nm
TCD 2015
(Railway)
42 Nm
A07 067 Overflow valve on connector
TCD 2015 39 Nm
TCD 2015
(Railway)
39 Nm
A07 068 Screw-in nipple on fuel shut-off valve TCD 2015 18 Nm
ID no. Name Screw type Notes / Remarks Series
Pre-clam-
ping value
Post-
clamping
value
