TCD 2015
Technical data
Tightening specifications
A12 031
V-belt pulley/torsional vibration damper on flan-
ged hub
oil lightly TCD 2015 30 Nm
A12 057
Bearing housing (hydraulic pump drive) on crank-
case
M10x55 oil lightly TCD 2015 30 Nm +60°
A12 058
Flange housing on bearing housing (hydraulic
pump drive)
M10x110 oil lightly TCD 2015 30 Nm +120°
A12 059
Flange housing on bearing housing (hydraulic
pump drive)
M10x210 oil lightly TCD 2015 30 Nm +180°
A12 071
Holder on gear case cover
M8x16-8.8 TCD 2015 18 Nm
TCD 2015
(Railway)
20 Nm
Heat shield on holder (gear case cover) M8x16-10.9 TCD 2015 20 Nm
A12 080 Fuel pipe on flame glow plug Union nut TCD 2015 20 Nm
A12 082 Oil pressure pipe Union nut
TCD 2015 39 Nm
TCD 2015
(Railway)
45 Nm
A12 090
Fuel hose to connector (overflow valve/fuel shut-
off valve)
Hollow screw
M10x1
TCD 2015 13 Nm
Pipe union with ring piece,
pipe 6 mm
TCD 2015
(Railway)
18 Nm
A12 092 Hollow screw pipe union with ring piece
Hollow screw
M14x1.5
Breather pipe on oil cooler
cover
TCD 2015 39 Nm
A12 093 Hollow screw pipe union M16x1.5
Fule pipe on fuel pressure
holding valve
TCD 2015 40 Nm
A12 095
Pipe clamps, fuel pipe to connecting pipe M6
TCD 2015
8.5 Nm
Fuel hose to air intake pipe Pipe clamp 8.5 Nm
Clip (cable) on holder (central plug) M8 18 Nm
