© 06/2006 8217-001
3/8
TCD 2015
Fuel system
W 07-04-01
6
z Visually inspect the components.
© 40807-0
Removing injection pump housing
z Remove fuel pipes.
W 07-10-06
z Remove fuel pipes (Railway).
W 07-10-06
z Unscrew screws (1).
z Remove injection pump housing (2).
Lay out components in the order in which
they should be installed.
Note cylinder assignment.
1
2
© 40811-0
z Visually inspect the components.
© 40812-0
