© 06/2006 8218-001
3/14
TCD 2015
Fuel system
W 07-06-04
6
z Unscrew hollow screw (1).
z Place fuel hose (2) to one side.
z Remove sealing rings.
1
2
© 40458-0
The injection pump cams for cylinder
no. A1 must be on the base circle (arrow).
© 42163-1
z Oil the roller tappet lightly.
z Insert roller tappet.
Note the assignment of the roller tappet.
The pilot pin (1) must lock in
groove (arrow).
1
© 42164-1
