C
HAPTER
4
| Basic Management Tasks
Managing System Files
– 103 –
PARAMETERS
The following parameters are displayed:
◆ Copy Type – The firmware copy operation includes these options:
■
FTP Upgrade – Copies a file from an FTP server to the switch.
■
FTP Download – Copies a file from the switch to an FTP server.
■
HTTP Upgrade – Copies a file from a management station to the
switch.
■
HTTP Download – Copies a file from the switch to a management
station
■
TFTP Upgrade – Copies a file from a TFTP server to the switch.
■
TFTP Download – Copies a file from the switch to a TFTP server.
◆ FTP/TFTP Server IP Address – The IP address of an FTP/TFTP server.
◆ User Name – The user name for FTP server access.
◆ Password – The password for FTP server access.
◆ File Type – Specify Operation Code or Loader.
◆ File Name –
The file name should not contain slashes (\ or /),
the
leading letter of the file name should not be a period (.), and the
maximum length for file names is 32 characters for files on the switch
or 128 characters for files on the server. (Valid characters: A-Z, a-z,
0-9, “.”, “-”, “_”)
◆ Auto reboot after opcode upgrade completed. – Automatically
reboots the switch after the operation code has been upgraded.
N
OTE
:
Up to two copies of the system software (i.e., the runtime firmware)
can be stored in the file directory on the switch.
N
OTE
:
The maximum number of user-defined configuration files is limited
only by available flash memory space.
N
OTE
:
The file
“
Factory_Default_Config.cfg
”
can be copied to a TFTP server
or management station, but cannot be used as the destination file name on
the switch.
WEB INTERFACE
To copy firmware files:
1. Click System, then File.
2. Select Copy from the Action list.
3. Select FTP Upgrade, HTTP Upgrade, or TFTP Upgrade as the file transfer
method.
