C
HAPTER
35
| Quality of Service Commands
– 883 –
EXAMPLE
This example creates a policy called “rd-policy,” uses the class command to
specify the previously defined “rd-class,” uses the set ip dscp command to
classify the service that incoming packets will receive, and then uses the
police flow command to limit the average bandwidth to 100,000 Kbps, the
burst rate to 4000 bytes, and configure the response to drop any violating
packets.
Console(config)#policy-map rd-policy
Console(config-pmap)#class rd-class
Console(config-pmap-c)#set ip dscp 3
Console(config-pmap-c)#police flow 10000 4000 conform-action transmit
violate-action drop
Console(config-pmap-c)#
set phb This command services IP traffic by setting a per-hop behavior value for a
matching packet (as specified by the match command) for internal
processing. Use the no form to remove this setting.
SYNTAX
[no] set phb phb-value
phb-value
- Per-hop behavior value. (Range: 0-7)
DEFAULT SETTING
None
COMMAND MODE
Policy Map Class Configuration
COMMAND USAGE
◆ The set phb command is used to set an internal QoS value in hardware
for matching packets (see Table 123, "Default Mapping of DSCP Values
to Internal PHB/Drop Values"). The QoS label is composed of five bits,
three bits for per-hop behavior, and two bits for the color scheme used
to control queue congestion by the police srtcm-color command and
police trtcm-color command.
◆ The set cos and set phb command function at the same level of
priority. Therefore setting either of these commands will overwrite any
action already configured by the other command.
