270 Upgrade and Maintenance Manual
RX2520 M4
Accessible drives
Figure 167: Fastening the ODD latch
Ê Fasten the ODD latch with two screws.
Figure 168: Installing the ODD (A)
Ê Thread front panel cable C1 and USB cable C2 through the bay of the
chassis.
Ê Insert the ODD module.
