RX2520 M4
Upgrade and Maintenance Manual
291
Accessible drives
Figure 192: I
nstalling the L
TO (B)
Ê
Thread all cables through the bay
.
Ê
Carefully push the front panel cage into it
s bay
.
Figure 193: Installing the front
panel module
Ê
T
ake note of the marked recess in the locking lever (
see close-up).
290
292
