RX2520 M4
Upgrade and Maintenance Manual
321
Fron
t pan
el
For Installations with L
TO drive
Figure 221: Lock and screw for installations with L
TO drive
For installations without
L
TO drive
Figure 222: Lock
for installations without L
TO drive
1
Lock
2
screw to fasten the front panel cage
when a L
TO drive is installed.
320
322
