Fujitsu PRIMERGY RX2520 M4 Upgrade And Maintenance Manual

RX2520 M4 Upgrade and Maintenance Manual 375
System board and components
Figure 265: FBU mounting positions
Ê The mounting positions are located on the air duct:
Ê Install the air duct, see section "Installing the air duct" on page 62.
1FBU 1
2 FBU 2 or Dual microSD 64GB Enterprise
