192 Upgrade and Maintenance Manual TX300 S7 / RX350 S7
Power supply
Figure 89: Mounting the power backplane (B)
Ê Lower the new power backplane into the chassis.
Ê Secure the power backplane on the spacer bolts with five screws (see
circles).
