TX300 S7 / RX350 S7 Upgrade and Maintenance Manual 269
Hard disk drives / solid state drives
Power cabling
Cabling solution 1:
Cabling solution 2:
I Alternative power cabling solution with power cable T26139-Y3939-
V202 for configurations involving a 4x 3.5-inch HDD extension box.
Cable
(T26139-)
Cabling
list no.
from to
Cabling
plan
HDD power cable
Y3952-V601
1
Power backplane
connector X21
SAS backplane 1
connector X7
(HDDs 1, 4, 7, 10)
Cable connector P1
16.2.5
SAS backplane 2
connector X7
(HDDs 2, 5, 8, 11)
Cable connector P2
4x 3.5-inch HDD
extension box SAS
backplane connector
X7 (HDDs 3, 6, 9, 12)
Cable connector P4
Cable
(T26139-)
Cabling
list no.
from to
Cabling
plan
HDD power cable
Y3952-V601
1
Power backplane
connector X21
SAS backplane 1
connector X7
(HDDs 1, 4, 7, 10)
Cable connector P1
16.2.6
SAS backplane 2
connector X7
(HDDs 2, 5, 8, 11)
Cable connector P2
(connector P4
remains unused)
