Fujitsu PRIMERGY TX300 S8 User Manual

248 Upgrade and Maintenance Manual TX300 S8 / RX350 S8
Hard disk drives / solid state drives
SAS cabling
Power cabling
Cable
(T26139-)
Cabling
list no.
from to
Cabling
plan
SAS cable
Y3963-V151/V101
16
Connector X1 on
SAS expander board
SAS backplane 1
connector X1
16.2.8
SAS cable
Y3963-V151/V101
17
Connector X2 on
SAS expander board
SAS backplane 2
connector X1
SAS cable
Y3963-V201
19
Connector X3 on
SAS expander board
2x 3.5-inch HDD
extension box SAS
backplane connector
X1
SAS cable
Y3963-V151/V101
16
Connector MLC 1 on
SAS controller 1 in
PCI slot 10
Connector MLC 1 on
SAS expander board
16.2.8
SAS cable
Y3963-V151/V101
16
Connector MLC 2 on
SAS controller 1 in
PCI slot 10
Connector MLC 2 on
SAS expander board
Cable
(T26139-)
Cabling
list no.
from to
Cabling
plan
HDD power cable
Y3952-V601
1
Power backplane
connector X21
SAS backplane 1
connector X7
(HDDs 1, 4, 7, 9)
Cable connector P1
16.2.6
SAS backplane 2
connector X7
(HDDs 2, 5, 8, 10)
Cable connector P2
HDD / ODD power
cable
Y4029-V201
3
System board
connector
PWR HDD/ODD
2x 3.5-inch HDD
extension box SAS
backplane connector
X4 (HDDs 3, 6)
16.2.6
